Elysium has released 3D-SUITE EX11.0.1.
Key Enhancement
Added new check items to PMI Checker
Common check items for PMI
- Unattached PMI without Leader Termination
- Verifies that the PMI is properly attached to another PMI or to a surface
Check items for datums
- Datum Feature Unassociated with Higher-precedence Datum
- Verifies that datum features used as datum references are defined with geometric tolerances referencing higher precedence datums
- Untoleranced Datum Feature
- Verifies whether the datum feature is controlled by a geometric tolerance or a size dimension, either directly or indirectly
