Latest Version: EX 10.0.4 (Released in July 2024)
Explore all modules of our 3DxSUITE – Adapters, Optimizers, Front-ends and Utility Tools. Configure your individual solution now.
Adapters
Adapters are Components of 3DxSUITE to process input and output. Adapters for capturing input data are called Importer. Adapters for the output to a target format are called Exporter.
3DxSUITE Importer and Exporter enable you to translate 3D data, including geometry, structures, attributes and PMI.
| CAD | Type | Format | Importer | Exporter | Supported Version | ||||
| Geometry | Attribute | PMI | Geometry | Attribute | PMI | ||||
| CATIA V5 | Plug-in | CATProduct CATPart cgr |
✓ | ✓ | ✓ | ✓ | ✓ | ✓ | R27 – R34(V5-6R2024) SmartLauncher (CAD Plug-in): R27 – R33 |
| Standalone | CATProduct CATPart |
✓ | ✓ | Import: R10 – R34(V5-6R2024) Export: R14, R19, R20, R21, R22 |
|||||
| CATIA V4 | Standalone | model | ✓ | ✓ | V4.2.1 – V4.2.5 | ||||
| 3DEXPERIENCE | Plug-in | – | ✓ | ✓ | ✓ | ✓ | ✓ | R2018x – R2024x SmartLauncher (CAD Plug-in): R2018x – R2023x |
|
| NX | Plug-in | prt | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | NX10 – NX 2312 Series SmartLauncher (CAD Plug-in): NX11 – NX 2306 Series Drawing Validator: NX 1847 Series – NX 2306 Series |
| Standalone | prt | ✓ | n/a | n/a | n/a | UG10 – NX 2306 Series | |||
| Creo Parametric | Plug-in | prt asm |
✓ | ✓ | ✓ | ✓ | ✓ | ✓ | 4.0 – 11.0 SmartLauncher (CAD Plug-in): Creo Parametric 4.0 – 10.0 Drawing Validator: 4.0 – 10.0 |
| Standalone | prt asm |
✓ | n/a | n/a | n/a | 2000i – 10.0 | |||
| NX I-deas | Plug-in | mf1 arc |
✓ | ✓ | ✓ | ✓ | ✓ | ✓ | 6.6 – 6.9 |
| SOLIDWORKS | Plug-in | sldasm sldprt |
✓ | ✓ | ✓ | ✓ | ✓ | ✓ | 2018 – 2024 SmartLauncher (CAD Plug-in): 2018 – 2023 |
| Creo Elements/Direct | Plug-in | Import: pkg, sda, sdp, sd Export: pkg |
✓ | ✓ | 20.0 – 20.7 | ||||
| Autodesk Inventor | Plug-in | iam ipt |
✓ | ✓ | ✓ | ✓ | 2019 – 2024 Drawing Validator: 2020 – 2024 |
||
| Solid Edge | Plug-in | asm, par, psm | ✓ | ✓ | n/a | n/a | n/a | 2020 – 2024 | |
| CADmeister | Standalone | cfio | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | V4.0 – V14.0 |
| iCAD SX | Standalone | icd | ✓ | ✓ | V7L1 – V8L3 | ||||
| Parasolid | Standalone | x_t x_b xmt_txt xmt_bin |
✓ | ✓ | V7 – V36.1 | ||||
| ACIS | Standalone | sat | ✓ | ✓ | R6 – R34 | ||||
| STEP | Standalone | step stp stpZ |
✓ | ✓ | ✓ | ✓ | ✓ | ✓ | AP203, AP214, AP242(ed1/ed2/ed3) |
| JT | Standalone | jt | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | Import: v6.4 – v10.10 Export: v9.0 – v10.9 |
| PLM XML | Standalone | plmxml | ✓ | ✓ | ✓ | ✓ | – | ||
| XPDMXML | Standalone | xml | ✓ | ✓ | ✓ | ✓ | – | ||
| 3D PDF | Standalone | ✓ | ✓ | ✓ | ✓ | Adobe Acrobat Reader DC | |||
| Creo View | Standalone | pvs, ol, pvz | n/a | n/a | n/a | ✓ | Creo View 1.0 or later | ||
| 3DXML | Standalone | 3dxml | ✓ | n/a | n/a | n/a | R2010x – R2024x | ||
| QIF | Standalone | qif | ✓ | ✓ | ✓ | ✓ | 2.1 – 3.0 | ||
| IGES | Standalone | igs iges |
✓ | ✓ | 5.2, 5.3 | ||||
| STEP XML | Standalone | stpx stpxZ |
✓ | ✓ | ✓ | ✓ | AP242 edition1 (IS), AP242 edition1 (TC), AP242 edition3 | ||
| STL | Standalone | stl | ✓ | ✓ | – | ||||
| XVL | Standalone | xv3 xv2 xv0 |
n/a | n/a | n/a | ✓ | ✓ | ✓ | P-XVL(V3), V-XVL(V5, V7, V9), U-XVL(V10, V11) |
| OBJ | Standalone | obj | ✓ | ✓ | – | ||||
| VRML | Standalone | wrl wrz vrml |
✓ | ✓ | – | ||||
| Nastran | Standalone | bdf dat |
✓ | n/a | n/a | n/a | – | ||
| Point Cloud | Standalone | Import: txt, asc, xyz, e57 Export: txt, asc, xyz |
✓ | ✓ | – | ||||
Optimizers
Optimizers are Components to perform various processing on 3D data imported into 3DxSUITE. Our Optimizers help you to leverage your 3D data through analyses, optimization and reporting.
| PDQ Checker | Use this Optimizer to run quality checks for your CAD models. PDQ checker complies with PDQ guidelines from SASIG, JAMA, JAPIA, and VDA. Check criteria and thresholds can be customized. Output your PDQ results in CSV or 3D PDF format for reporting or utilize them to increase your data quality with our healing capabilities. |
| DFX |
Plug-in for DFM Use this Optimizer for manufacturability check. (Former DFM Studio) Plug-in for DFAS Use this Optimizer for automotive safety check. (Former DFAS Studio) |
| CAD Validator | Use this Optimizer for automated CAD validation. Compare two CAD models including geometry, assembly structures, attributes and PMI. Changes are output in customizable validation reports. We offer you four types of validation reports in these formats: 2D XML, 3D HTML, 3D PDF and a dedicated viewer. |
| Drawing Validator |
Use this Optimizer to validate 2D drawings. |
| Geometry Simplifier | Use this Optimizer to simplify your CAD data. Remove specific features for CAE analyses, easily delete and combine components for IP protection, or create envelope solids for file size reduction. We enable the reuse of your simplified models for space claim, product packaging, AR/VR applications and many more use cases. |
| Reverse Engineer | Use this Optimizer to run reverse engineering. We can automatically recognize fillets and base surfaces from polygon curvature for further processing and optimization. Automate the process to create CAD models from polygon data and utilize high-quality data for your downstream processes. |
| Mid Surfacer | Use this Optimizer to create mid-surfaces for analyses. Semi-automatically create mid-surfaces from solid models. Leverage your data with specific editing functions exclusively for mid-surfaces. |
| Polygon Optimizer | Use this Optimizer to streamline your polygon data. Perform quality checks and optimize your polygon data for further downstream consumption. |
| ENF Editor | Use this Optimizer to edit your ENF data. Information contained in ENF, such as assembly structures, colors, attributes and PMI can be edited freely. It will operate by calling ENF Editor API from a Ruby script. The script can be edited freely. |
| Report Creator | Use this Optimizer to create your 3D reports. Report Creator is required to output PDQ Checker / CAD Validator output results into a 3D PDF or 3D HTML report. |
Utility Tools
Utility Tools are used to configure various settings of 3DxSUITE components. Our Utility Tools enable you to customize the behavior and outputs of 3DxSUITE components to meet your individual requirements. All Utility Tools can be used license-free.
| Common Utility | Common Utility is a tool for editing and implementing general settings of our 3DxSUITE Components. Settings configured by Common Utility are automatically applied to each available 3DxSUITE Component. |
| ScenarioEditor | ScenarioEditor is a tool for the definition of reusable scenarios. Specify the Components to be executed by placing Adapters and Optimizers in the GUI. You define the order of processing steps, configure the individual parameters of each Component within a scenario and control their relations. |
| Data Package Studio | Data Package Studio is a tool for customizing your 3D PDF output. It works as a plug-in for Adobe Acrobat Pro product line and provides you maximum flexibility to create reusable templates. |
| Validation Configurator | Validation Configurator is a tool for customizing the comparison process performed by CAD Validator. You can define which of the various elements included in the 3D model to use in the comparison. A rich set of settings and filters gives you full control to highlight your significant changes. |
| PDQ Checker Configurator | PDQ Checker Configurator is a tool for customizing the analysis of our PDQ Checker. It is provided in Microsoft Excel format. |
Front-ends
Our Front-ends provide interfaces of 3DxSUITE to users and administrators to perform dedicated operations. We offer desktop applications, web applications, Windows context menus, CAD built-in menus, and command line operation to support your desired use cases.
| License Type | Standard | Enterprise | |
| Viewer | With our Viewer you can visualize 3D model data in ENF format and compare result output by CAD Validator. It operates lighter than Editor, allowing users to perform various measurements and display structures. | ✔ | ✔ |
| Editor | With our Editor you can view, automatically translate and edit 3D model data. Manual editing gives you full control for optimizing your 3D model data. Editor is the equivalent to our older product, CADdoctor. | ✔ | ✔ |
| SmartLauncher | Standalone With our SmartLauncher Standalone you can run Component processing from Windows context menu. In addition to translation, you can call reusable scenarios to automatically run a series of operations. Plug-in With our SmartLauncher Plug-in you can run Component processing from the menu within your CAD system. The CAD integration avoids switching systems in your daily operations. You can directly import external formats to your native CAD application and export to an external format. Scenarios can be called to automatically run a series of operations. CAD Connector CATIA V5, NX, Creo Parametric, SOLIDWORKS Optional products of SmartLauncher (CAD Plug-in) for connecting Viewer and CAD via Inspector. |
✔ | ✔ |
| SmartController | With our SmartController you can process multiple 3D model data together based on your specified scenarios. It provides limited batch functionality as all processing is done on a single computer. | ✔ | ✔ |
| SmartController Pro | With our SmartController Pro you can process multiple 3D model data together based on your specified scenarios. It is the high-end version of our SmartController and provides full batch functionality via execution on multiple computers. | ✔ | |
| TransServer | TransServer is a high-end product of SmartController Pro and runs on web-based. You can execute scenarios for 3D model data translation and optimization and distribute the loads. TransServer also offers a variety of functions such as user management, execution process via Web API, and automatic translation of 3D model data located in specific folders. | ✔ | |
| WorkerNode | With our WorkerNodes the Component processes such as translation and CAD comparison can be executed based on the commands from SmartController Pro and TransServer. | ✔ | |
| Command Line | Command Line is a method to directly run Components from the command line without using an application. | ✔ | |
| Inspector | Application to display the exported result from DFX Analyzer. | ✔ | ✔ |
| Drawing Validator Viewer | Application to edit the report exported from Drawing Validator | ✔ | ✔ |
License Type
There are two types of license to leverage 3DxSUITE Adapters, Optimizers, and Front-ends.
Standard
- Multiple Front-Ends for desktop applications
- Integration into CAD systems via Plug-ins
- Scenario utilization to increase reuse
- Easy execution of sophisticated capabilities
- Manual operations by users
- Limited batch functionality
Enterprise
- Multiple Front-Ends from desktop applications to fully automated enterprise solutions
- Scenario utilization to increase reuse
- Full batch functionality with load balancing and command line
- PDM integration and web-based systems
- Scalability
Quick Comparison Table for Standard and Enterprise
| Standard | Enterprise | |
| Desktop applications | ✔ | ✔ |
| Interactive execution | ✔ | ✔ |
| CAD system integration | ✔ | ✔ |
| Scenario utilization | ✔ | ✔ |
| Simple Batch processing | ✔ | ✔ |
| Full Batch Functions (Load Balancing, Command Line) |
✔ | |
| PDM integration | ✔ | |
| Automation for high throughput | ✔ |
Looking for a Bundle? For common use cases we offer preconfigured Bundle Package.
